12-24 IM 701450-01E
Loading the Waveform Data
Set the data type to Binary. For the setup procedure, see steps 4 and 5 on page 12-21.
6. Press the Load soft key. The Load menu and the File List window appear.
Selecting the Load Source Medium/Directory
7. The procedure is the same as steps 14 and 15 on page 12-22.
Selecting the File to Be Loaded
8. Turn jog shuttle to select a file.
Executing the Load Operation
9. Press the Load Exec soft key. The selected file is read from the directory
indicated in Path=...... At the same time, the Load Exec soft key changes to the
Abort soft key.
Aborting the Load Operation
10. Press the Abort soft key. The load operation is aborted. At the same time, the
Abort soft key changes to the Load Exec soft key.
Specifying the File to Be Displayed in the File List Window and Viewing File
Properties
11. The procedure is the same as steps 22 to 25 on page 12-23.
Unloading the Waveform Data
6. After step 5 of page 12-21, press the Unload soft key. The Unload menu is
displayed.
7. Press the Trace soft key. The Trace menu appears.
8. Press the All, CH1 to CH8(4), Math1, Math2, Pod A, or Pod B soft key to
select the waveform data to be unloaded.
• On the DL7440, you can select from All, CH1 to CH4, Math1, Math2, Pod A, and Pod
B. Math1, Math2, Pod A, and Pod B appear when you press the Next (1/2) soft key.
• On the DL7480, you can select from All, CH1 to CH8, Math1, Math2, Pod A, and Pod
B. CH5, CH6, CH7, CH8, and Math1 appear when you press the To Page 2 soft key.
Math2, Pod A, and Pod B appear when you press the To Page 3 soft key.
• If you select All, all the channels are unloaded.
9. Press the Unload Exec soft key. The unload operation is executed.
12.8 Saving/Loading the Waveform Data
To Next Page
