12-23
IM 701450-01E
12
Saving and Loading Data
Executing the Save Operation
20. Press the Save Exec soft key. The data is saved to the directory indicated by
Path=...... At the same time, the Save Exec soft key changes to the Abort soft
key. While the data is being saved, the
icon is displayed at the upper left
corner of the screen.
Aborting the Save Operation
21. Press the Abort soft key. The save operation is aborted. At the same time, the
Abort soft key changes to the Save Exec soft key.
Specifying the File to Be Displayed in the File List Window and Viewing File
Properties
22. On the screen showing the File List window, press the Filter soft key to select
∗.extension or ∗.∗.
• If you select ∗.extension (WVF, CSV, or FLD), only the files that have the same file
format as the file being saved are displayed.
• If you select ∗.∗, all the files in the directory are displayed.
23. Turn jog shuttle to select the files in the File List window.
24. Press the Property soft key. Information about the selected file is displayed.
25. Press ESC. The window showing the information closes.
12.8 Saving/Loading the Waveform Data
To Next Page
