4-12 IM 701450-01E
Selecting Toggle Box Items on the Dialog Box
Left-click the item you wish to select. The item is selected. Click the selected item again
to deselect it. To close the dialog box, point to an area outside the dialog box and left-
click.
Left-click the item
you wish to select.
Note
To close an error dialog box, left- or right-click or turn the mouse wheel without moving the
mouse.
Selecting a File, Directory, or Disk Drive on the File List Window
Left-click a file, directory, or disk drive name to select it. Turn the mouse wheel to scroll
through the file list. To cancel the selection, point to an area outside the file list window
and left-click. The selection is cancelled, and the file list window closes.
Move the pointer to the file, directory, or storage
medium you wish to select and left-click.
Scroll bar
4.3 Operating the DL7400 Using a USB Keyboard or a USB Mouse
