CELL-DYN

3/35 Sample Loader TS Guide 9140234B-June 1997

VERIFICATION PROCEDURES

VP - 6.1 Mixing Head Position Check

3 - 81

Book TOC

Go Back

Figure 3-38 Location of Adjustment/Alignment Tools

d. Load Mixin

Head Ali

nment Tool in Position # 4 of Rack and Place Rack on Left End of

Platen.

Place Rack Guide

Ali

nment Tool

with Cutout Up

and Facin

Left

SL-243

# 4

Mixin

Head

Ali

nment Tool

Mixin

Paddle

Main Page
