6241A/6242 DC Voltage Current Source/Monitor Operation Manual
5.2.3 Sweep Source Mode Operation
5-14
2. Changing Sweep Measurement Parameter
Sweep measurement parameter is basically changeable only in Standby or Suspend status, but the fol-
lowing items are changeable in Sweep stop status during operation.
• Time parameter
• Hold time
• Source delay time
• Measurement delay time
• Pulse width
• Period time
• Random-sweep Start-address and Stop-address
(These are changeable in the start address to stop address range when moved from Standby sta-
tus to Operate or Suspend.)
• Sweep function parameter
• Number of repetitions
• Reverse mode ON and OFF
• RTB ON and OFF
• Measurement auto range ON and OFF
• Measurement ON and OFF
• Measurement integration time
• Selecting COMPLETE OUT or SYNC OUT external control signal output-function
3. Indicator Display for Sweeping Status
indicates sweeping status is on.
Sweeping: The indicator rotates.
HOLD: Indicator stops rotation but remains displayed.
STOP: Indicator is not displayed.
