6241A/6242 DC Voltage Current Source/Monitor Operation Manual
5.2.4 Source Function
5-24
2. The Range a source value is set in (Sweep range is Auto)
6241A
6242
3. Operational Range during Sweep
The period time may be extended if a range change occurs while sweeping. For more information on
the sweep operation in this case, see Table 5-5, “DC Sweep Source Mode” or Table 5-6, “Pulse Sweep
Source Mode Operation.”
If the period time is extended, TpALM indicator illuminates.
Source function Setting value Range set
Voltage-source 0 mV |Vs| 320.00 mV 300 mV
320.00 mV < |Vs| 3.2000 V 3 V
3.2000 V < |Vs| 32.000 V 30 V
Current-source 0 μA |Is| 32.000 μA 30 μA
32.000 μA < |Is| 320.00 μA 300 μA
320.00 μA < |Is| 3.2000 mA 3 mA
3.2000 mA < |Is| 32.000 mA 30 mA
32.000 mA < |Is| 320.00 mA 300 mA
320.00 mA < |Is| 500.00 mA 500 mA
Source function Setting value Range set
Voltage-source 0 mV |Vs| 320.00 mV 300 mV
320.00 mV < |Vs| 3.2000 V 3 V
3.2000 V < |Vs| 06.000 V 6 V
Current-source 0 μA |Is| 32.000 μA 30 μA
32.000 μA < |Is| 320.00 μA 300 μA
320.00 μA < |Is| 3.2000 mA 3 mA
3.2000 mA < |Is| 32.000 mA 30 mA
32.000 mA < |Is| 320.00 mA 300 mA
320.00 mA < |Is| 3.0000 A 3 A
3.0000 A < |Is|
5.0000 A 5 A
