6241A/6242 DC Voltage Current Source/Monitor Operation Manual
6.6 Data Output Format (Talker Format)
6-19
1. Header
The header is not output if it is set to OFF.
Main header
DV: DC voltage measurement
DI: DC current measurement
RM: DC current measurement (resistance displayed)
EE: Data not in the specified measurement memory
Sub header
Sub header
Main header
U: High limit occurs.
B: Low limit occurs.
O: Range over
Z: For resistance measurement, the voltage-source value is set to 0 (zero).
F: For resistance measurement, the current-source value is below 20 counts
or current-measurement value is below 200 counts.
E: Calculation error (scaling function or total function)
H: The comparator calculation result is HI.
G: The comparator calculation result is GO.
L: The comparator calculation result is LO.
C: Scaling calculation data
N: NULL calculation data
:Others (space output)
High
Priority
Low
