6.7.3 Remote Command List
6-29
Sweep
Random sweep
memory data
N [adr]
P
Random sweep memory data setting starts from N com-
mand and completes at P command.
N<adr>,SVR<n>,SOV<data1>,SOV
<data2>,...,P (voltage setting)
N<adr>,SIR<n>,SOI<data1>,SOI
<data2>,...,P (current setting)
adr: Memory address (0
to 7999)
data1: adr address voltage or current-source
value
data2: Voltage or Current-source value of the
address adr + 1
0
0
*6
N? [adr]
Res
ponse:
N<a
dr>,SVR<n>,
SOV
± <data>,P(Voltage-source value)
N<adr>,SIR<n>,SOI ± <data>,P
(Current-source value)
adr: <dddd>
n: <d>
data: <d.ddddE ± d>
*1
NP? Query of the random sweep memory setting status
Response: 0... Random sweep memory setting complete
1... Random sweep memory is setting.
0
RSAV Saves the random sweep data.
RLOD Loads the random sweep data.
RCLR Initializes the random sweep data. (Data saved in mem-
ory is not initialized.)
Pulse sweep base
value
BS [data] data: Pulse sweep base value
0
BS? Response: BS ± <d.ddddE ± d>
*1
Bias value SB [data] data: Bias value
0
SB? Response: SB ± <d.ddddE ± d>
*1
RTB
(Return To Bias)
RB0 OFF (Stays at the final output value when sweep
is stopped.)
RB1 ON (Returns to bias value when sweep is
stopped.)
RB? Response: RB0 or RB1
*1: The response decimal point is different depending on the set value.
For the source value, limit value, and time parameter set up range, refer to the performance specifications.
*6: It is not initialized by RINI or *RST command.
Item Command Description
Default Operation
Power
ON
Default
setting
During DC/
pulse
operation and
suspension
During
sweep
operation and
suspension
Note:
1. Not specifying the source range causes the FIT
range to be specified.
2. A source value different from the current-source
function cannot be set.
To Next Page
