6241A/6242 DC Voltage Current Source/Monitor Operation Manual
6.7.3 Remote Command List
6-35
System
Comparator cal-
culation results
buzzer
BZ0 OFF
BZ1 ON (when the comparator calculation result is HI)
BZ2 ON (when the comparator calculation result is GO)
BZ3 ON (when the comparator calculation result is LO)
BZ4
ON (when the comparator calculation result is HI or LO)
BZ?
Response: BZ0
to BZ4
Limit detection
buzzer
UZ0 OFF
UZ1 ON
UZ? Response: UZ0 or UZ1
Self test *TST? Executes and reads out the results.
Response: 0; Pass
1; Fail
TER? Returns self test result of each register.
Response: a, b, c, and d
(a, b, c, and d are equivalent to 0 to 65535.)
Error log ERL? Reads out error description.
Number of errors and error descriptions are cleared.
Response: ± ddd, ± ddd, ± ddd, ± ddd, ± ddd
(+ is shown as a space)
ERC? Reads out the number of errors.
Response: ddd
000: No error
001 to 999: Number of errors (006 to 999: Can
be overwritten)
Interlock setting OP0 Inputs the STBY In signal (IN).
OP1 Inputs the OPR/SRBY In signal (IN).
OP2 Inputs the Interlock In signal (IN).
OP3 Outputs the Operate Out signal (OUT).
OP4 Inputs the OPR/SUS In signal (IN).
OP?
Response: OP0
to OP4
Item Command Description
Default Operation
Power
ON
Default
setting
During DC/
pulse
operation and
suspension
During
sweep
operation and
suspension
To Next Page
