6241A/6242 DC Voltage Current Source/Monitor Operation Manual
6.7.3 Remote Command List
6-39
Commands for maintaining compatibility with previous models
Item Command Description
Default Operation
Power
ON
Default
setting
During DC/
pulse
operation
During
sweep
operation
Source Source range
function and
source range
V3 Voltage source function of 300 mV range
Sus-
pended
when
executed
V4 Voltage source function of 3 V range
V5 Voltage source function of 30 V range/6 V range
I-1 Current source function of 30 µA range
I0 Current source function of 300 µA range
I1 Current source function of 3 mA range
I2 Current source function of 30 mA range
I3 Current source function of 300 mA range
I4 Current source function of 500 mA range/3 A
range
I5 Current source function of 5 A range
*9
V?
Response: V3
to V5 or I1 to I5
I?
Source value
(Pulse value)
andLimiter value
D ± data UNIT Source setting is different depending of the UNIT
used.
With UNIT:
Automatically sets the optimal range.
Available units; mV, V, µA, mA, A
Without UNIT:
Set the current source function and
range.
If specifying a unit that is different from the cur-
rent source function, the limiter value will be set
as shown below.
+data is High limiter value.
-data is Low limiter value.
D? Response: D ± <data1>UNIT,D <data2>UNIT
data1: Voltage or current source value
<d.ddddE ± d>
*1
data2: Voltage or current-limiter value
(The polarity is space)
<0d.dddE ± d>
*1
UNIT: V or A
*9: Results in an error in the 6241A.
Note:
If the absolute values of High and Low limits are dif-
ferent, the response becomes D± d.ddddE ± dUNIT,
D09.999E + 9 UNIT.
