6241A/6242 DC Voltage Current Source/Monitor Operation Manual
6.7.3 Remote Command List
6-38
Cali-
bra-
tion
Calibration switch CAL0 OFF (Exits the calibration mode.)
CAL1 ON (Enters the calibration mode.)
CAL? Response: CAL0 or CAL1
Calibration data XINI Initializes the calibration data area. (Calibration data in
non-volatile memory is not initialized.)
XWR Saves the calibration data in non-volatile memory.
Executing calibra-
tion
XVS Selects voltage source function calibration.
XIS Selects current source function calibration.
XVLH Selects voltage limiter (High) calibration.
XVLL Selects voltage limiter (Low) calibration.
XILH Selects current-limiter (High) calibration.
XILL Selects current-limiter (Low) calibration.
XVM Selects voltage measurement function calibration.
XIM Selects current measurement function calibration.
Calibration range
XR-1
XR0
XR1
XR2
XR3
XR4
XR5
Sets the calibration range.
Calibration data XDAT Changes to the DMM data input mode.
XD data: Inputs DMM read data.
XADJ Changes to the calibration data fine adjustment mode.
XUP Fine adjusts the calibration data (UP).
XDN Fine adjusts the calibration data (DOWN).
XNXT Moves on to the next calibration.
*5: It is not initialized by RINI command.
*6: It is not initialized by RINI or *RST command.
*9: Results in an error on the 6241A.
Item Command Description
Default Operation
Power
ON
Default
setting
During DC/
pulse
operation and
suspension
During
sweep
operation and
suspension
Voltage range Current range
XR-1 - 30 μA
XR0 - 300 μA
XR1 - 3 mA
XR2 - 30 mA
XR3 300 mV 300 mA
XR4 3 V 500 mA/3 A
XR5 30 V/6 V 5 A
*9
