6241A/6242 DC Voltage Current Source/Monitor Operation Manual
8.2.4 Calibration Points and Tolerance Range
8-17
Current HI limiter 30 μA
0 A
+30.00 μA5 nA
300 μA +300.0 μA50 nA
3 mA +3.000 mA 500 nA
30 mA +30.00 mA 5 μA
300 mA +300.0 mA 50 μA
3 A +3.000 A 500 μA
5 A +5.000 A 1 mA
Current LO limiter 30 μA
0 A
-30.00 μA5 nA
300 μA -300.0 μA50 nA
3 mA -3.000 mA 500 nA
30 mA -30.00 mA 5 μA
300 mA -300.0 mA 50 μA
3 A -3.000 A 500 μA
5 A -5.000 A 1 mA
Item Range
Calibration point
Tolerance
range
ZERO F.S
