6241A/6242 DC Voltage Current Source/Monitor Operation Manual
9.1.2 6242 Source and Measurement
9-14
Over shoot: ±0.1% or less
Resistive load, at end of standard cable (except for 30 μA, 300 μA,
3 A, 5 A range)
Line regulation: ±0.003% of range or less
Load regulation: Voltage-source; ±0.003 % of range or less (At 4-wire connection with
maximum load)
Source
range
Limiter
range
Settling time
Output response
FAST SLOW
Voltage-source
(Output current: 5 A)
300 mV
5 A
300 μs or less 1 ms or less
3 V 200 μs or less 500 μs or less
6 V 400 μs or less 800 μs or less
Current-source
(Output voltage: 6 V)
30 μA
6 V
2 ms or less 3 ms or less
300 μA
200 μs or less 600 μs or less
3 mA
30 mA
300 mA
3 A
700 μs or less 1.5 ms or less
5 A
Typical value
Source
range
Limiter
range
Settling time
Output response
FAST SLOW
Voltage-source
(Output current: with less than 20% of full
scale load)
300 mV
3 mA to
300 mA
35 μs or less 300 μs or less
3 V 30 μs or less 200 μs or less
6 V 40 μs or less 300 μs or less
Current-source
(Output voltage: 1 V)
30 μA
3 V
800 μs or less 1 ms or less
300 μA
30 μs or less 200 μs or less
3 mA
30 mA
300 mA
3 A
100 μs or less 300 μs or less
5 A
