6241A/6242 DC Voltage Current Source/Monitor Operation Manual
2.2.1 Setting Source Value
2-20
2. Press 3, ., 1 in this order.
While inputting values, the cursor blinks.
3. Press ENTER.
The numeric value has been applied and the direct input mode is released.
4. Press the 123…, 1, 0, ENTER keys in order to set +10 V.
(For the 6242, the maximum range for setting is ±6 V.)
• If the FIT indicator turns off, the value exceeds the 3 V setting range and an
error occurs. The value cannot be set.
• When the FIT indicator turns on, the optimum 30 V range is set.
Blinking
Cursor (blinking)
Blinking
Cursor (blinking)
To Next Page
