Source Impedance
The analyzer’s source impedance is less than 5 ohms. It is designed to be
operated into nearly any type of load. If your device-under-test requires a
specific source impedance, place an appropriate resistor in series with the
analyzer’s source output.
Synthesizing Complex Waveforms
You can generate a complex waveform function with a computer program. An
example program, “ARBSRC,” which generates an arbitrary source waveform
is available on the GPIB Example Programs disk. The program listing is
printedinAppendixFof
GPIB Programmming with the Agilent 35670A.
Agilent 35670A
Operator's Guide The Arbitrary Source Option 1D4
6-3
