To save a limit
1 Activate the trace containing the limit you want to save.
2 Press [
Save/Recall
][
SAVE MORE
], then press [
SAVE UPPER LIM
]or[
SAVE LOWER LIM
].
3 Type a file name, then press [
ENTER
].
After you press [
ENTER
], the analyzer saves the upper or lower limit in the current
directory of the default disk. If more than one trace is active, the limit is saved from
the most active trace. (For a definition of the most active trace, see online help for the
[
Active Trace
] hardkey.) Once you have saved a limit, you can copy it to any active
trace with the [
RECALL UPPER LIM
]or[
RECALL LOWER LIM
] softkey—located under
[
Save/recall
][
RECALL MORE
].
The analyzer has eight limit registers: one upper and one lower limit register for each
of the four traces. Each register holds a complete limit. The contents of these
registers are not altered when you preset the analyzer, but they are lost when you turn
off the analyzer. If you create limits that you want to reuse, it’s best to save them to a
flexible disk so they won’t be lost.
Agilent 35670A
Limit Testing Operator's Guide
17-6
