Agilent Technologies 35670A User Manual

5 Modify the waveform.
Press [
Analys
][
DEFINE FUNCTION (F1-F5)
].
Press [
DEFINE F1
][
MEAS DATA
].
Press [
CHANNEL 1 2 3 4
] to highlight 1.
Press [
TIME CHANNEL 1
].
Press [
*
].
Press [
DATA REGISTER (D1 - D8)
][
DATA REG D1
].
Press [
ENTER
].
6 Configure the display.
Press [
Meas Data
][
MORE CHOICES
][
MATH FUNCTION
][
F1
].
Press [
Trace Coord
][
MORE CHOICES
][
REAL PART
].
Press [
Scale
], then press[
AUTOSCALE ON OFF
] to highlight ON.
7 Configure the arbitrary source.
Press [
Save/Recall
][
SAVE DATA
][
SAVE TRACE
][
INTO D2
].
Press [
Source
][
MORE CHOICES
][
ARB SRC SETUP
][
DATA REG D2
].
Press [
Rtn
].
Press [
ARBITRARY (D1 - D8)
].
This task uses a ramp signal as a weighting function for the periodic chirp waveform.
Step 5 specifies a math function that does the multiplication and stores the result.
A: CH1Time X:0 s Y:-188.391uV
0s 7.8049ms
2.5
V
-2.5
V
Real
500
mV
/div
MeasData
[FFT]
A: CH1Time B: CH2Pwr Spec
C: CH1Time D: CH2Time
F1 = Time1* D1
F2
F3
F4
F5
K1 = 1.000000 + j 0.000000
K2 = 2.000000 + j 0.000000
K3 = -1.000000 + j 0.000000
K4 = 0.000000 + j 1.000000
K5 = 0.000000 - j 1.000000
Agilent 35670A
Operator's Guide The Arbitrary Source Option 1D4
6-9
