To select/convert a table format — Pole-Residue format
1 Press [
Analys
][
SYNTHESIS
][
CONVERT TABLE
].
2 Press [
CONVRT TO POLE RESD
].
3 Press [
TABLE ON OFF
] to highlight ON.
The left column contains poles and the right column contains residues.
The 1s^0 residue term appears when you convert an empty table (interpreted as
H(s) =1) to the pole-residue format. If you do not need to use the 1s^0 residue term,
clear the table.
Avoid converting tables unnecessarily.
POLES 3 SYNTH RESIDUES
-250
-500 j 2e+3
86.154
-43.077 j -244.62
TIME DELAY=0 s
FREQUENCYSCALE=1
GAIN=1
Agilent 35670A
Synthesis Option 1D3 Operator's Guide
