To convert a displayed transducer unit
1 Activate the trace whose transducer unit you want to convert.
2 Press [
Trace Coord
][
Y UNITS
][
XDCR UNIT CONVERT
].
3 Press the softkey corresponding to the unit you want to use for displayed amplitude
values.
The following transducer units are used to quantify acceleration, velocity, and
displacement:
• g, m/s^2, inch/s^2 (acceleration)
• m/s, inch/s (velocity)
• m, inch, mil (displacement)
If you selected one of these units in the previous task, the analyzer allows you to
quickly convert displayed amplitude values to any one of the others. This feature is
useful when your transducer quantifies energy using one unit but you want to display
results using another.
Agilent 35670A
Operator's Guide Selecting Display Units
11-7
