To set top and bottom values for the Y-axis
1 Activate the trace you want to scale.
2 Press [
Scale
][
TOP REFERENCE
] <number> [
BOTTOM
] <number> [
ENTER
].
When you press [
TOP REFERENCE
], an entry window is displayed at the top of the
screen. You can use this window in one of two ways:
• You can enter a new value for the top of the Y-axis (as described in the previous
task).
• You can enter new values for both the top and the bottom of the Y-axis (as
described in this task).
The first number you type is used as the value for the top of the Y-axis. [
BOTTOM
]
inserts a comma, indicating that the second number you type should be used as the
value for the bottom of the Y-axis. [
ENTER
] completes the numeric entry, causing the
new values to take effect.
Agilent 35670A
Scaling the Display Operator's Guide
10-4
