Tosetupanexternaldisk
1 Turn off your external disk drive and analyzer, then connect their GPIB ports with an
GPIB cable.
2 Turn on the disk drive and analyzer.
3 Determine the disk drive’s GPIB address.
4 On the analyzer, press [
Local/GPIB
][
DISK ADDRESS
] <number> [
ENTER
].
You can use one of the Agilent 10833 GPIB cables to connect the analyzer to your
external disk drive. These cables range in length from 0.5 to 4 meters. They are
available through your local Agilent Technologies, Inc. Sales and Service Office.
Refer to your external disk’s documentation if you don’t know how to turn it on or
determine its GPIB address. When you determine the address, write it down; this is
the value you will substitute for <number> in step 4.
GPIB Connector
Agilent 35670A
Managing Files and Disks Operator's Guide
13-2
