To select a coordinate system
1 Activate the trace you want to display in a different coordinate system.
2 Press [
Trace Coord
].
3 If you want to see magnitude versus frequency (or time), press one of the following:
[
LINEAR MAGNITUDE
], [
LOG MAGNITUDE
], or [
dB MAGNITUDE
].
4 If you want to see phase versus frequency, press [
PHASE
]or[
UNWRAPPED PHASE
].
5 If you want to see time versus frequency, press [
MORE CHOICES
][
GROUP DELAY
].
6 If you want to see real or imaginary values, press [
MORE CHOICES
], then press one of
the following: [
REAL PART
], [
IMAGINARY PART
], [
NYQUIST DIAGRAM
], or
[
POLAR DIAGRAM
].
The coordinate system determines which unit selections (made in the following tasks)
will apply to the X-axis and Y-axis. For example, the phase unit selection only applies
when you select a coordinate system that displays phase.
Note: The options you select under the [
Meas Data
] hardkey can limit the availability
of coordinate systems.
Agilent 35670A
Selecting Display Units Operator's Guide
11-2
