Agilent Technologies 35670A

To view the results of a math operation
1 Specify the active trace. See “To select the active trace” in chapter 8.
2 Press [
Meas Data
][
MORE CHOICES
][
MATH FUNCTIONF2 55P255J0].
3 Press [
F1
].
or
Press [
F2
].
or
Press [
F3
].
or
Press [
F4
].
or
Press [
F5
].
4 Press [
Scale
][
AUTOSCALE ON OFF
] to highlight ON.
A math function must be defined before it can be displayed. If you display a math
function that cannot be executed, the analyzer displays the grid with no data.
Functions are stored in volatile RAM. They remain after a preset, but are lost if you
cyclepower. Saveamathfunctiontoafilebeforepower-downoritwillbelost.
Agilent 35670A
Math Operations and Data Editing Operator's Guide
18-8
