To display a synthesis table — Pole-Zero Format
1 Press [
Analys
][
SYNTHESIS
].
If you do not already have an existing table in the pole-zero format,
press [
CONVERT TABLE
]
[
CONVRT TO P OLE ZERO
].
2 Press [
TABLE ON OFF
] to highlight ON.
The left column contains poles, the right column contains zeros.
• Poles (or zeros) can be either real (simple) or complex conjugate pairs.
• Α±jΒ distinguishes a complex conjugate pair from a simple pole or zero.
Avoid converting tables unnecessarily.
POLES 3 SYNTH ZEROS 1
-250
-500 j 2e+3
-600
TIME DELAY=0 s
FREQUENCYSCALE=1
GAIN=1e+06
-250
Agilent 35670A
Operator's Guide Synthesis Option 1D3
15-15
