Agilent Technologies 35670A

To change the synthesis register
1 Press [
Analys
][
SYNTHESIS
][
SYNTHESIS REGISTER
].
2 Press [
D1
]
or
Press [
D2
]
or
Press [
D3
]
or
Press [
D4
]
or
Press [
D5
]
or
Press [
D6
]
or
Press [
D7
].
The synthesis trace is stored in a dedicated data register. The default register is D8.
The data for the trace is saved as real and imaginary values versus frequency.
Therefore, you do not need to save magnitude and phase to two separate data registers.
If you change the synthesis register, your selection is stored in RAM. If you preset the
analyzer, the selection returns to the default data register, D8.
Agilent 35670A
Operator's Guide Synthesis Option 1D3
15-35
