To display amplitude in dBm
1 Activate the appropriate trace.
2 Press [
Trace Coord
][
dB MAGNITUDE
].
3 Press [
Y UNITS
][
dB REF SETUP
][
dBm
].
4 Press [
dBm REF IMPEDANCE
], then enter the impedance of your test device.
To display dBm, you must have the dB magnitude trace coordinate selected. Also,
transducer units must be turned off. See “To select a transducer unit” if you don’t
know how to turn off transducer units.
Agilent 35670A
Selecting Display Units Operator's Guide
11-8
