To select the frequency/time unit
1 Activate the trace whose frequency/time unit you want to select.
2 Press [
Trace Coord
][
X UNITS
].
3 Press one of the following: [
HZ (SEC)
], [
CPM (SEC)
], or [
ORDER (REV)
].
4 If you pressed [
ORDER (REV)
], press [
ORDER SETUP
][
HZ/ORDER RATIO
], then enter the
frequency corresponding to one order (in Hz or rpm).
If you prefer, you can use the marker to set the value of [
HZ/ORDER RATIO
]. Just turn
the knob to place the marker on the frequency corresponding to one order, then press
[
ORDER AT MKR
].
Note: The options you select under the [
Meas Data
] and [
Trace Coord
] hardkeys can
limit the availability of X-axis units.
Agilent 35670A
Operator's Guide Selecting Display Units
11-3
