To select the phase unit
1 Activate the trace whose phase unit you want to select.
2 Press [
Trace Coord
][
Y UNITS
].
3 If you want phase values displayed in degrees, press [
PHASE DEG RAD
] to highlight
DEG.
4 If you want phase values displayed in radians, press [
PHASE DEG RAD
] to highlight
RAD.
Phase values are displayed only when you select one of the following softkeys (under
the [
Trace Coord
] hardkey): [
PHASE
], [
UNWRAPPED PHASE
], or [
POLAR
].
Agilent 35670A
Selecting Display Units Operator's Guide
11-4
