Performing the
Synthesis
After data is entered in a synthesis table, you are ready to perform the
synthesis. Analyzer configuration affects the synthesis frequency span and the
X-axis data spacing of the synthesis trace.
The analyzer uses the frequency-span set up for measurements to determine the
synthesis start and stop frequencies. For example, you could set the span to
12.8 kHz with a start frequency at 0 Hz. Once you set the start and stop
frequencies, you do not have to set them for subsequent synthesis calculations.
Synthesis data spacing for the X-axis can be either linear or logarithmic. Set
the X-axis spacing before performing the synthesis. The default setting is
linear.
The synthesized trace is stored in a data register and displayed in the active
trace when the synthesis is complete.
