To annotate a plot or print
1 Press [
Plot/Print
][
MORE SETUP
], then press [
TITLE ON OFF
] to highlight ON.
2 Press [
TITLE LINE 1
], type the first line of annotation, and press [
ENTER
].
3 Press [
TITLE LINE 2
], type the second line of annotation, and press [
ENTER
].
4 If you want to include the current time and date, press [
TIME STMP ON OFF
] to highlight
ON.
5 Complete one of the following tasks: “To plot screen contents” or “To print screen
contents.”
You can modify the format of the time stamp by pressing [
System Utility
]
[
CLOCK SETUP
][
TIME STMP SETUP
], and then pressing the softkey that corresponds to
format you want to use. See online help for more information on the time stamp
formats.
Time stamp.
Plot/print annotation replaces the mini-state at
the top of the screen.
Agilent 35670A
Operator's Guide Plotting and Printing
14-7
