Agilent Technologies 35670A

To add a gain factor, time delay, and frequency scale to the
synthesis calculation
1 Create and display a synthesis table.
2 Press [
SYNTHESIS SETUP
].
3 Press [
GAIN FACTOR
]<number>.
4 Press [
TIME DELAY
] <number> <unit>.
5 Press [
FREQUENCY SCALE
] <number> <unit>.
POLES 3 SYNTH ZEROS 1
-250
-500 j 2e+3
-600
TIME DELAY=0 s
FREQUENCYSCALE=1
GAIN=1e+06
-250
Optional parameters appear at the bottom
of the table.
You must enter these parameters before
creating the synthesized frequency
response trace.
Agilent 35670A
Operator's Guide Synthesis Option 1D3
15-23
