Agilent 35670A Operations
The Agilent 35670A provides numerous operations and operands to build
a math function.
Operations include:
AWEIGHT
Applies an A-weight filter
BWEIGHT
Applies a B-weight filter
CWEIGHT
Applies C-weight filter
CONJ
Complex Conjugate
DIFF
Differentiate
/JOMEGA
divide by j ω
EXP
Exponential
FFT
Fast Fourier Transform
INVERSE FFT
Inverse Fast Fourier
Transform
INTEG
Integrate
IMAG
Imaginary Part
LN
Natural Logarithm
MAG
Magnitude
PSD
Power Spectral Density
REAL
Real Part
SQRT
Square Root
*JOMEGA
multiply by j ω
Measurement data depends on instrument mode.
In FFT instrument mode, data selections include:
PWR SPEC
Power Spectrum
LIN SPEC
Linear Spectrum
TIME
Time Data
FREQ RESP
Frequency Response
COHERENCE
COH
CROS SPEC
Cross Spectrum
WINDOWED
TIME
Windowed Time Data
In octave analysis instrument mode (Option
1D1), data selections include:
PWR SPEC
Power Spectrum
In order analysis instrument mode (Option
1D0), data selections include:
PWR SPEC
Power Spectrum
TIME
Resampled Time
COMP PWR
Composite Power
ORDER TRK
Order Track
RPM Profile
In swept sine instrument mode (Option 1D2),
data selections include:
LIN SPEC
Linear Spectrum
TIME
Time Data
FREQ RESP
Frequency Response
CROS SPEC
Cross Spectrum
NORM VAR
Normalized Variance
In correlation instrument mode, data selections
include:
TIME
Time Data
AUTO CORR
Autocorrelation
CROS CORR
Cross Correlation
WINDOWED
TIME
Windowed Time Data
In histogram/time instrument mode, data
selections include:
HISTOGRAM
PDF
Probability Density
Function
CDF
Cumulative Density
Function
TIME
Unfiltered Time
Agilent 35670A
Math Operations and Data Editing Operator's Guide
18-6
