STATus:OPERation:
Program Examples - STATus:OPERation:CALL:COMMon
OUTPUT 714;”STATUS:OPERATION:CALL:COMMON:EVENT?” !Queries the Operation Call Common Event
!Register.
OUTPUT 714;”STATUS:OPERATION:CALL:COMMON:CONDITION?” !Queries the Operation Call Common
!Condition Register.
OUTPUT 714;”STATUS:OPERATION:CALL:COMMON:ENABLE 8” !Sets the Operation Call Common Enable
!Register for bit 3.
OUTPUT 714;”STATUS:OPERATION:CALL:COMMON:NTR 8” !Sets the Negative Transition
!Register for bit 3.
OUTPUT 714;”STATUS:OPERATION:CALL:COMMON:PTR 256” !Sets the Positive Transition
!Register for bit 8.
STATus:OPERation:CALL:COMMon:DATA Condition Register Bit Assignment
The STATus:OPERation:CALL:COMMon:DATA register bits are used to indicate status of processes that
occur during normal data connection processing operations.
Bit
Number
Binary
Weighting
Condition Description
15 32768 Not Used. Defined by SCPI. This bit is always 0.
14 16384 Reserved for future use. This bit is always 0.
13 8192 Reserved for future use. This bit is always 0.
12 4096 Reserved for future use. This bit is always 0.
11 2048 Reserved for future use. This bit is always 0.
10 1024 Reserved for future use. This bit is always 0.
9 512 Reserved for future use. This bit is always 0.
8 256 Reserved for future use. This bit is always 0.
7 128 Starting Data Connection This bit is a 1 when:
• Active Cell mode - the data connection status
leaves the idle state
• Test mode - the test set has noted a base station
origination.
6 64 Data Connection Status Changing This bit is set to a 1 when the data connection
status change detector has been armed.
5 32 Data Connection Status Off This bit is set to 1 when the test set is in the call
control status handover/handoff state.
4 16 Data Connection Status Data
Connected
This bit is set to 1 when data connection status data
is in the connected state.
3 8 Data Connection Status
Transferring
This bit is set to 1 when the data connection status
is Transferring.
