STATus:OPERation:
STATus:OPERation:KEYPressed Register Bit Assignments
The STATus:OPERation:KEYPressed register bits indicate when a softkey on the test set’s front panel has
been pressed while the test set is in remote operating mode.
Bit
Number
Binary
Weighting
Condition Description
15 32768 Not Used. Defined by SCPI. This bit is always 0.
14 16384 Reserved for future use. This bit is always 0.
13 8192 Reserved for future use. This bit is always 0.
12 4096 Reserved for future use. This bit is always 0.
11 2048 F12 softkey This bit is a 1 when the test set’s F12 softkey has
been pressed.
10 1024 F11 softkey This bit is a 1 when the test set’s F11 softkey has
been pressed.
9 512 F10 softkey This bit is a 1 when the test set’s F10 softkey has
been pressed.
8 256 F9 softkey This bit is a 1 when the test set’s F9 softkey has
been pressed.
7 128 F8 softkey This bit is a 1 when the test set’s F8 softkey has
been pressed.
6 64 F7 softkey This bit is a 1 when the test set’s F7 softkey has
been pressed.
5 32 F6 softkey This bit is a 1 when the test set’s F6 softkey has
been pressed.
4 16 F5 softkey This bit is a 1 when the test set’s F5 softkey has
been pressed.
3 8 F4 softkey This bit is a 1 when the test set’s F4 softkey has
been pressed.
2 4 F3 softkey This bit is a 1 when the test set’s F3 softkey has
been pressed.
1 2 F2 softkey This bit is a 1 when the test set’s F2 softkey has
been pressed.
0 1 F1 softkey This bit is a 1 when the test set’s F1 softkey has
been pressed.
