STATus:OPERation:
STATus:OPERation:CALL:DIGital2000 Register Bit Assignment
The STATus:OPERation:CALL:DIGital2000 register bits will be used to indicate status of processes that occur
during DIGital2000 call processing operations.
Program Examples - STATus:OPERation:CALL
OUTPUT 714;”STATUS:OPERATION:CALL:DIGITAL2000:EVENT?”
!Queries the Operation Call DIGital2000 Event Register.
OUTPUT 714;”STATUS:OPERATION:CALL:DIGITAL2000:CONDITION?”
!Queries the Operation Call DIGital2000Condition Register.
OUTPUT 714;”STATUS:OPERATION:CALL:DIGITAL2000:ENABLE 2”
!Sets the Operation Call DIGital2000Enable Register for bit 1.
OUTPUT 714;”STATUS:OPERATION:CALL:DIGITAL2000:NTR 4”
!Sets the DIGital2000 Negative Transition Register for bit 2.
OUTPUT 714;”STATUS:OPERATION:CALL:DIGITAL2000:PTR 256”
!Sets the DIGital2000 Positive Transition Register for bit 8.
Bit
Number
Binary
Weighting
Condition Description
15 32768 Not Used. Defined by SCPI. This bit is always 0.
14 16384 Reserved for future use. This bit is always 0.
13 8192 Reserved for future use. This bit is always 0.
12 4096 Reserved for future use. This bit is always 0.
11 2048 Reserved for future use. This bit is always 0.
10 1024 Reserved for future use. This bit is always 0.
9 512 Reserved for future use. This bit is always 0.
8 256 Reserved for future use. This bit is always 0.
7 128 Reserved for future use. This bit is always 0.
6 64 Reserved for future use. This bit is always 0.
5 32 Reserved for future use. This bit is always 0.
4 16 Reserved for future use. This bit is always 0.
3 8 Reserved for future use. This bit is always 0.
2 4 Reserved for future use. This bit is always 0.
1 2 F-SCH Synchronized. 1 indicates that a 10.24 second sync frame boundary
has been encountered and a valid TDSO FER
measurement can now be initiated.
0 1 Extension Bit This bit is always 0.
