Test Application Revisions and Licenses
Test Application Revisions and Licenses
Description
Different revisions of the test applications in your test set provide different capabilities. The selected test
application revision is loaded after the next test application switch or power cycle of the test set. Once you
select a revision the revision does not change unless you select another revision.
You can query the selected revision, all available revisions, and the total count of available revisions for a
selected test application. These queries are helpful when selecting revisions but are not usually necessary
when switching test applications.
NOTE The Agilent E1960A GSM mobile test application revisions prior to A.04.00 do not support test
application switching. If you select a revision prior to A.04.00 you will not have a path to switch
back to later revisions.
If you accidentally switch to a non-supported revision, use the firmware upgrade process to load
firmware with the correct revision.
Test Application Revision Queries and Commands
These are commands to query revision information or select a revision.
• To query a selected test application revision (running or not) use this GPIB command:
OUTPUT 714;”SYSTEM:APPLICATION:SELECT:REVISION? ‘AMPS/136 MOBILE TEST’”
• To query the revision of the test application currently running use this GPIB command:
OUTPUT 714;”SYSTEM:APPLICATION:CURRENT:REVISION?”
• To query all of the revisions available for a test application use this GPIB command:
OUTPUT 714;”SYSTEM:APPLICATION:CATALOG:REVISION? ‘AMPS/136 MOBILE TEST’”
• To select a revision of a test application use this GPIB command:
OUTPUT 714;”SYSTEM:APPLICATION:SELECT:REVISION ‘GSM mobile test’,’A.04.01’”
• To query the number of revisions for a specified test application:
OUTPUT 714;”SYSTEM:APPLICATION:CATALOG:REVISION:COUNT? ‘GSM MOBILE TEST’”
