Test Adherence to Standards
3.4.13 Behavior of the Quality Indicator Bit of the
Forward Dedicated Control Channel
No, possible future enhancement
3.5.1 Receiver Sensitivity and Dynamic Range Yes
3.5.2 Single Tone Desensitization Tests 1 and 2 Yes, with external signal generator
3.5.3 Intermodulation Spurious Response Attenuation
Tests 1 and 2
Yes, with external signal generator
3.5.4 Adjacent Channel Selectivity Yes, with external CDMA generator
3.6.1 Conducted Spurious Emissions No, use the HP 859XE +HP 85725C CDMA Spectrum
Analyzer
3.6.2 Radiated Spurious Emissions No, use the HP 859XE +HP 85725C CDMA Spectrum
Analyzer
3.7.1 Supervision Paging Channel Partially, but the test set does not provide timing
measurements
3.7.2 Supervision Forward Channel - Test 1 and Test 2 No
4.1 Transmit Frequency Accuracy Yes, uses the rho or EVM measurement method
4.2.1 CDMA to CDMA Hard Handoff Partially, performs F
1
to F
2
Hard handoffs, but cannot
make the required timing measurement
4.2.2 Transmit Power after Hard Handoff No
4.2.3 Candidate Frequency Single Search No
4.3.1 Time Reference Yes, uses the rho or EVM measurement method.
Time Reference Slew Rate Partially, requires an external fader & external timing
measurement device. E1962A requires mobile test mode to
set-up call
4.3.2 Reverse Pilot Channel to Code Channel Time
Tolerance
Yes
4.3.3 Reverse Pilot Channel to Code Channel Phase
Tolerance
Yes
4.3.4 Waveform Quality and Frequency Accuracy Yes, uses the rho or EVM measurement method. The test
set also measures multi-coded waveform quality, a
non-standard but more useful measurement.
4.3.5 Code Domain Power Yes
4.4.1 Range of Open Loop Output Power Yes, Uses access probe power measurement. Enhanced
Access Channel is not currently supported.
Table 8. IS-98-D Standards
TIA/EIA-98-D E1962B
