134 Chapter 4
Calibration
Full 3-Port and Full 4-Port Calibration using 2-Port ECal
Figure 4-27 ECalAssistant (Connection) dialog box
Step 14. Re-connect the ECal module following the instructions given in each dialog box and
continue the calibration process.
Step 15. When all calibration data have been collected, a dialog box with the Complete! sign
appears as shown in
Figure 4-28. Press the Done button to finish the calibration. If you
wish to cancel the calibration, press the Cancel button.
Figure 4-28 EcalAssistant (Finish) dialog box
