Agilent Technologies ENA Series

194 Chapter 4
Calibration
Changing the Calibration Kit Definition
85052D
1. Short 2. Open 5. 3.5/2.92 6. 3.5/SMA 7. 2.92/SMA
Label Short Open 3.5/2.92 3.5/SMA 3.5/SMA
STD Type Short Open Open Open Open
C0 [×10
-15
F]
0 49.433 6.9558 5.9588 13.4203
C1 [×10
-27
F/Hz]
0 -310.131 -1.0259 -11.195 -1.9452
C2 [×10
-36
F/Hz
2
]
0 23.1682 -0.01435 0.5076 0.5459
C3 [×10
-45
F/Hz
3
]
0 -0.15966 0.0028 -0.00243 0.01594
L0 [×10
-12
H]
2.0765 0 0 0 0
L1 [×10
-24
H/Hz]
-108.54 0 0 0 0
L2 [×10
-33
H/Hz
2
]
2.1705 0 0 0 0
L3 [×10
-42
H/Hz
3
]
-0.01 0 0 0 0
Offset Delay [s] 31.785 p 29.243 p 0 0 0
Offset Z0 [Ω] 50 50 50 50 50
Offset Loss [Ω/s] 2.36 G 2.2 G 0 0 0
Arb. Impedance [Ω] 50 50 50 50 50
8. 2.4/1.85 9. Broadband 11. Thru 13. Adapter
Label 2.4/1.85 Broadband Thru Adapter
STD Type Open Load Delay/Thru Delay/Thru
C0 [×10
-15
F]
8.9843 0 0 0
C1 [×10
-27
F/Hz]
-13.9923 0 0 0
C2 [×10
-36
F/Hz
2
]
0.3242 0 0 0
C3 [×10
-45
F/Hz
3
]
-0.00112 0 0 0
L0 [×10
-12
H]
0 0 0 0
L1 [×10
-24
H/Hz]
0 0 0 0
L2 [×10
-33
H/Hz
2
]
0 0 0 0
L3 [×10
-42
H/Hz
3
]
0 0 0 0
Offset Delay [s] 0 0 0 94.75 p
Offset Z0 [Ω] 50 50 50 50
Offset Loss [Ω/s] 0 0 0 2.51 G
Arb. Impedance [Ω] 50 50 50 50
