Chapter 6 271

Data Analysis

Determining the Bandwidth of the Trace (Bandwidth Search)

6. Data Analysis

executed. The response value of this active marker itself is the insertion loss in the

bandwidth search (

loss).

Step 2. Press .

Step 3. Press Bandwidth Value and enter the defined bandwidth value in the entry area that

appears.

Step 4. Press Bandwidth to turn on the bandwidth search. In the upper left of the trace display, six

bandwidth parameters are displayed (

Figure 6-14).

Figure 6-14 Bandwidth search results (defined bandwidth = −3 dB)
