Table 16-11 Test Port Input (Trace Noise)
Description Specification Supplemental Information
Trace Noise
*1.Trace noise is defined as a ratio measurement of a through, at IFBW = 3 kHz.
*1
Magnitude
300 kHz to 3 MHz
(source power level = +10 dBm)
5 mdB rms (typical)
8 mdB rms (high temperature
mode: ON, typical)
3 MHz to 3 GHz
(source power level = +10 dBm)
1 mdB rms (23°C±5°C) 4 mdB rms (high temperature
mode: ON, typical)
3 GHz to 4.25 GHz
(source power level = +9 dBm)
1.2 mdB rms (23°C±5°C) 4.8 mdB rms (high temperature
mode: ON, typical)
4.25 GHz to 6 GHz
(source power level = +7 dBm)
3.6 mdB rms (23°C±5°C) 7.2 mdB rms (high temperature
mode: ON, typical)
6 GHz to 7.5 GHz
(source power level = +5 dBm)
3.6 mdB rms (23°C±5°C) 7.2 mdB rms (high temperature
mode: ON, typical)
7.5 GHz to 8.5 GHz
(source power level = +5 dBm)
6 mdB rms (23°C±5°C) 9.6 mdB rms (high temperature
mode: ON, typical)
Trace Noise
*1
Phase
300 kHz to 3 MHz
(source power level = +10 dBm)
0.035 ° rms (23°C±5°C, typical)
0.05 ° rms (high temperature
mode: ON, typical)
3 MHz to 3 GHz
(source power level = +10 dBm)
0.007 ° rms (23°C±5°C, typical)
0.02 ° rms (high temperature
mode: ON, typical)
3 GHz to 4.25 GHz
(source power level = +9 dBm)
0.008 ° rms (23°C±5°C, typical)
0.024 ° rms (high temperature
mode: ON, typical)
4.25 GHz to 6 GHz
(source power level = +7 dBm)
0.025 ° rms (23°C±5°C, typical)
0.042 ° rms (high temperature
mode: ON, typical)
6 GHz to 7.5 GHz
(source power level = +5 dBm)
0.025 ° rms (23°C±5°C, typical)
0.042 ° rms (high temperature
mode: ON, typical)
7.5 GHz to 8.5 GHz
(source power level = +5 dBm)
0.042 ° rms (23°C±5°C, typical)
0.06 ° rms (high temperature
mode: ON, typical)
