Sweep Range (without extended power range)
300 kHz to 4.25 GHz
4.25 GHz to 6 GHz
6 GHz to 8.5 GHz
−15 dBm to 10 dBm
−15 dBm to 8 dBm
−15 dBm to 6 dBm
−20 dBm to 10 dBm
−20 dBm to 8 dBm
−20 dBm to 6 dBm
Level Resolution 0.05 dB
Table A-6 Test Port Input Levels
Description Specification Supplemental Information
Maximum Test Port Input Level
300 kHz to 4.25 GHz
4.25 GHz to 6 GHz
6 GHz to 8.5 GHz
+10 dBm
+8 dBm
+6 dBm
Damage Level
300 kHz to 8.5 GHz +20 dBm, ±25 VDC, typical
Crosstalk
*1.Response calibration not omitted.
*1
3 MHz to 3 GHz
3 GHz to 6 GHz
6 GHz to 7.5 GHz
7.5 GHz to 8.5 GHz
−120 dB
−110 dB
−100 dB
−90 dB
*1.Source output performance on port 1 only. Other port output performance is typical.
Table A-7 Test Port Input (Trace Noise)
Description Specification Supplemental Information
Trace Noise
*1
Magnitude
300 kHz to 3 MHz
(source power level = +10 dBm)
5 mdB rms (typical)
8 mdB rms (high temperature
mode: ON, typical)
3 MHz to 4.25 GHz
(source power level = +10 dBm)
1 mdB rms (23°C±5°C) 4 mdB rms (high temperature
mode: ON, typical)
4.25 GHz to 6 GHz
(source power level = +8 dBm)
3 mdB rms (23°C±5°C) 6 mdB rms (high temperature
mode: ON, typical)
6 GHz to 7.5 GHz
(source power level = +6 dBm)
3 mdB rms (23°C±5°C) 6 mdB rms (high temperature
mode: ON, typical)
7.5 GHz to 8.5 GHz
(source power level = +6 dBm)
5 mdB rms (23°C±5°C) 8 mdB rms (high temperature
mode: ON, typical)
Trace Noise
*1
Phase
Table A-5 Test Port Output Power
*1
Description Specification Supplemental Information
