Appendix C 633
List of Default Values
List of Default Values, Save/Recall Settings, and Backup Settings
C. List of Default Values
Port Extensions
Extensions OFF ← ← √ K/C
Auto Port
Extension
Select Ports 1,2,3,4 ← ← √ K/C
Method Current Span ← ← √ K/C
User Span
Start
300.00 kHz ← ← √ K/C
User Span
Stop
3.0000 GHz (E5070B)
8.5000 GHz (E5071B)
← ← √ K/C
Adjust
Mismatch
OFF ← ← √ K/C
Include Loss OFF ← ← √ K/C
Extension Port1 OFF ← ← √ K/C
Extension Port2 OFF ← ← √ K/C
Extension Port3 OFF ← ← √ K/C
Extension Port4 OFF ← ← √ K/C
Loss
Select Port 1 ← ← √ K/C
Loss1 OFF ← ← √ K/C
Loss1 0.0000 dBm ← ← √ K/C
Freq1 1.0000 GHz ← ← √ K/C
Loss2 OFF ← ← √ K/C
Loss2 0.0000 dBm ← ← √ K/C
Freq2 1.0000 GHz ← ← √ K/C
Loss at DC 0.0000 dBm ← ← √ K/C
Velocity Factor 1.0000 ← ← √ K/C
Power Calibration
Select Port 1 ← ← K
Correction OFF ← ← √ K/C
Use Sensor A ← ← K
Num of Readings 1 ← ← √ K/C
Tolerance 5.000 dB ← ← √ K/C
Loss Compen
Compensation OFF ← ← √ K/C
Sensor A Settings
Ref Cal Factor 100.00% Non-changing ← √ K/C
Sensor B Settings
Ref Cal Factor 100.00% Non-changing ← √ K/C
Key Operation Factory-shipped Setting Default Value Save/
Recall
Backup Available
Means of
Defining a
Setting
*RST
To Next Page
