638 Appendix C
List of Default Values
List of Default Values, Save/Recall Settings, and Backup Settings
Fixture Simulator
BalUn OFF ← ← √ K/C
Port Matching
Port Matching OFF ← ← √ K/C
Select Port 1 ← ← √ K/C
Select Circuit None ← ← √ K/C
C 0.000e-12 F ← ← √ K/C
G 0.0000 S ← ← √ K/C
L 0.000e-9 H ← ← √ K/C
R 0.0000 Ω ← ← √ K/C
Port ZConversion
Port
ZConversion
OFF ← ← √ K/C
Port1 Z0 Real 50.000 Ω ← ← √ K/C
Port1 Z0 Imag 0.000 Ω ← ← √ K/C
Port2 Z0 Real 50.000 Ω ← ← √ K/C
Port2 Z0 Imag 0.000 Ω ← ← √ K/C
Port3 Z0 Real 50.000 Ω ← ← √ K/C
Port3 Z0 Imag 0.000 Ω ← ← √ K/C
Port4 Z0 Real 50.000 Ω ← ← √ K/C
Port4 Z0 Imag 0.000 Ω ← ← √ K/C
De-Embedding
De-Embedding OFF ← ← √ K/C
Select Port 1 ← ← √ K/C
Select Type None ← ← √ K/C
Diff Matching
Diff Matching OFF ← ← √ K/C
Select Bal Port 2 ← ← √ K/C
Select Circuit None ← ← √ K/C
C 0.000e-12 F ← ← √ K/C
G 0.0000 S ← ← √ K/C
L 0.000e-9 H ← ← √ K/C
R 0.0000 Ω ← ← √ K/C
Diff ZConversion
Diff
ZConversion
OFF ← ← √ K/C
Port1 (bal) Real 100.00 Ω ← ← √ K/C
Port1 (bal) Imag 0.00 Ω ← ← √ K/C
Port2 (bal) Real 100.00 Ω ← ← √ K/C
Port2 (bal) Imag 0.00 Ω ← ← √ K/C
Key Operation Factory-shipped Setting Default Value Save/
Recall
Backup Available
Means of
Defining a
Setting
*RST
To Next Page
