654 Appendix D
Softkey Functions
Analysis Menu
(Continued)
Fixture Simulator
Cmn
ZConversion
*1
Displays softkeys for setting up the common impedance conversion function. When the reference impedance of
two unbalanced ports is expressed as Z
0
, an automatic conversion sets the differential mode reference impedance
of the converted balanced port to 2Z
0
and the common mode reference impedance to Z
0
/2. Common impedance
conversion is a function that further converts Z
0
/2 into another reference impedance.
Cmn
ZConversion
Enables or disables the common impedance conversion function.
:CALC{1-16}:FSIM:BAL:CZC:STAT
Port1 (bal)
Real
*2
Sets the common reference impedance (real format) of balanced port 1.
:CALC{1-16}:FSIM:BAL:CZC:
BPOR1:Z0
:CALC{1-16}:FSIM:BAL:CZC:
BPOR1:REAL
Port1 (bal)
Imag
*2
Sets the common reference impedance (complex format) of balanced port 1.
:CALC{1-16}:FSIM:BAL:CZC:
BPOR1:IMAG
Port2 (bal) Real Sets the common reference impedance (real format) of balanced port 2.
:CALC{1-16}:FSIM:BAL:CZC:
BPOR{1-2}:Z0
:CALC{1-16}:FSIM:BAL:CZC:
BPOR{1-2}:REAL
Port2 (bal) Imag Sets the common reference impedance (complex format) of balanced port 2.
:CALC{1-16}:FSIM:BAL:CZC:
BPOR{1-2}:IMAG
Port3 (bal)
Real
*2
Sets the common reference impedance (real format) of balanced port 3.
:CALC{1-16}:FSIM:BAL:CZC:
BPOR1:Z0
:CALC{1-16}:FSIM:BAL:CZC:
BPOR1:REAL
Port3 (bal)
Imag
*2
Sets the common reference impedance (complex format) of balanced port 3.
:CALC{1-16}:FSIM:BAL:CZC:
BPOR1:IMAG
Return Returns to the softkey display screen one level higher.
De-Embedding S4P Displays the softkey to make the setting of the 4-port network embedding/de-embedding feature. The 4-port
network embedding/de-embedding feature is the feature to embed or de-embed your desired network that you have
defined in a 4-port touchstone data file.
De-Embedding
S4P
Toggles ON/OFF the 4-port network embedding/de-embedding feature.
:CALC{1-16}:FSIM:EMB:STAT
Topology Displays the softkey to assign a topology (the connection method between the analyzer and the DUT).
Select
Topology
Displays the softkey to select the type of the topology (see Figure 7-6).
A Selects topology A (connecting the 2 ports of the analyzer and the DUT).
:CALC{1-16}:FSIM:EMB:TYPE A
B
*1
Selects topology B (connecting the 2 ports of the analyzer and the DUT).
:CALC{1-16}:FSIM:EMB:TYPE B
C
*2
Selects topology C (connecting the 2 ports of the analyzer and the DUT).
:CALC{1-16}:FSIM:EMB:TYPE C
Cancel Returns to the softkey display screen one level higher.
Ports
*1
Displays the softkey to select a port of the analyzer (test port) that you want to connect to the DUT. (When you
select
A on the Select Topology menu.)
1-2 Sets the ports of the analyzer connected to ports a and b in Figure 7-6 to test
ports 1 and 2, respectively.
:CALC{1-16}:FSIM:EMB:TOP:A:PORT
1,2
1-3
*1
Sets the ports of the analyzer connected to ports a and b in Figure 7-6 to test
ports 1 and 3, respectively.
:CALC{1-16}:FSIM:EMB:TOP:A:PORT
1,3
1-4
*2
Sets the ports of the analyzer connected to ports a and b in Figure 7-6 to test
ports 1 and 4, respectively.
:CALC{1-16}:FSIM:EMB:TOP:A:PORT
1,4
2-1 Sets the ports of the analyzer connected to ports a and b in Figure 7-6 to test
ports 2 and 1, respectively.
:CALC{1-16}:FSIM:EMB:TOP:A:PORT
2,1
2-3
*1
Sets the ports of the analyzer connected to ports a and b in Figure 7-6 to test
ports 2 and 3, respectively.
:CALC{1-16}:FSIM:EMB:TOP:A:PORT
2,3
Key Operation Function SCPI Command
