Agilent Technologies ENA Series

668 Appendix D
Softkey Functions
Calibration Menu
(Continued)
Calibrate
3-Port Cal
*1
Transmission
Port y-z Thru Executes a THRU calibration on test ports y and z. :SENS{1-16}:CORR:COLL:THRU y,z
:SENS{1-16}:CORR:COLL:THRU z,y
Return Returns to the softkey display screen one level higher.
Isolation
(Optional)
Displays softkeys for executing isolation calibrations. Symbols x, y, and z refer to the three test ports selected in
the
Select Ports menu (x, y, and z are always 1, 2, and 3, respectively, for models with Option 313 or 314).
Port x-y Isol Executes an isolation test on test ports x and y. :SENS{1-16}:CORR:COLL:ISOL x,y
:SENS{1-16}:CORR:COLL:ISOL y,x
Port x-z Isol Executes an isolation test on test ports x and z. :SENS{1-16}:CORR:COLL:ISOL x,z
:SENS{1-16}:CORR:COLL:ISOL z,x
Port y-z Isol Executes an isolation test on test ports y and z. :SENS{1-16}:CORR:COLL:ISOL y,z
:SENS{1-16}:CORR:COLL:ISOL z,y
Return Returns to the softkey display screen one level higher.
Done Terminates a calibration process and calculates the calibration
coefficients.
:SENS{1-16}:CORR:COLL:SAVE
Overwrite Terminates partial overwrite and recalculates the calibration
coefficients.
:SENS{1-16}:CORR:COLL:PART:SAVE
Cancel Displays softkeys for canceling a calibration.
OK Cancels a calibration process and clears the measurement data of
standard.
:SENS{1-16}:CORR:COLL:CLE
Cancel Returns to the softkey display screen one level higher.
Return Returns to the softkey display screen one level higher.
4-Port Cal
*2
Displays softkeys for executing full 4-port calibrations.
Reflection Displays softkeys for executing reflection calibrations.
Port 1 Open Executes an OPEN calibration on test port 1.
:SENS{1-16}:CORR:COLL:OPEN 1
Port 1 Short Executes a SHORT calibration on test port 1.
:SENS{1-16}:CORR:COLL:SHOR 1
Port 1 Load Executes a LOAD calibration on test port 1.
:SENS{1-16}:CORR:COLL:LOAD 1
Port 2 Open Executes an OPEN calibration on test port 2.
:SENS{1-16}:CORR:COLL:OPEN 2
Port 2 Short Executes a SHORT calibration on test port 2.
:SENS{1-16}:CORR:COLL:SHOR 2
Port 2 Load Executes a LOAD calibration on test port 2.
:SENS{1-16}:CORR:COLL:LOAD 2
Port 3 Open Executes an OPEN calibration on test port 3.
:SENS{1-16}:CORR:COLL:OPEN 3
Port 3 Short Executes a SHORT calibration on test port 3.
:SENS{1-16}:CORR:COLL:SHOR 3
Port 3 Load Executes a LOAD calibration on test port 3.
:SENS{1-16}:CORR:COLL:LOAD 3
Port 4 Open Executes an OPEN calibration on test port 4.
:SENS{1-16}:CORR:COLL:OPEN 4
Port 4 Short Executes a SHORT calibration on test port 4.
:SENS{1-16}:CORR:COLL:SHOR 4
Port 4 Load Executes a LOAD calibration on test port 4.
:SENS{1-16}:CORR:COLL:LOAD 4
Return Returns to the softkey display screen one level higher.
Transmission Displays softkeys for executing transmission calibrations.
Port 1-2 Thru Executes a THRU calibration between test ports 1 and 2. :SENS{1-16}:CORR:COLL:THRU 1,2
:SENS{1-16}:CORR:COLL:THRU 2,1
Port 1-3 Thru Executes a THRU calibration between test ports 1 and 3. :SENS{1-16}:CORR:COLL:THRU 1,3
:SENS{1-16}:CORR:COLL:THRU 3,1
Port 1-4 Thru Executes a THRU calibration between test ports 1 and 4. :SENS{1-16}:CORR:COLL:THRU 1,4
:SENS{1-16}:CORR:COLL:THRU 4,1
Key Operation Function SCPI Command
