Agilent Technologies ENA Series

670 Appendix D
Softkey Functions
Calibration Menu
(Continued)
Calibrate
2-Port TRL Cal
Thru/Line Displays softkeys for executing THRU/LINE calibrations. Symbols x and y refer to the two test ports selected in
the
Select Ports menu (x and y are always 1 and 2, respectively, for models with Option 213 or 214).
x-y Thru/Line Executes a THRU/LINE calibration on test ports x and y.
:SENS{1-16}:CORR:COLL:TRLT x,y
:SENS{1-16}:CORR:COLL:TRLT y,x
Return Returns to the softkey display screen one level higher.
Reflect Displays softkeys for executing reflection calibrations. Symbols x and y refer to the two test ports selected in the
Select Ports menu (x and y are always 1 and 2, respectively, for models with Option 213 or 214).
Port x
Reflect
Executes a OPEN/SHORT reflection calibration on test port x.
:SENS{1-16}:CORR:COLL:TRLR x
Port y
Reflect
Executes a OPEN/SHORT reflection calibration on test port y.
:SENS{1-16}:CORR:COLL:TRLR y
Return Returns to the softkey display screen one level higher.
Line/Match Displays softkeys for executing LINE/MATCH calibrations. Symbols x and y refer to the two test ports selected in
the
Select Ports menu (x and y are always 1 and 2, respectively, for models with Option 213 or 214).
x-y
Line/Match
Executes a LINE/MATCH calibration on test ports x and y.
:SENS{1-16}:CORR:COLL:TRLL x,y
:SENS{1-16}:CORR:COLL:TRLL y,x
x-y Fwd(Syx) Executes a forward LINE/MATCH calibration on test ports x and y.
:SENS{1-16}:CORR:COLL:TRLL y,x
x-y Rvs(Sxy) Executes a reverse LINE/MATCH calibration on test ports x and y.
:SENS{1-16}:CORR:COLL:TRLL x,y
Return Returns to the softkey display screen one level higher.
Done Terminates a calibration process and calculates the calibration
coefficients.
:SENS{1-16}:CORR:COLL:SAVE
Cancel Displays softkeys for canceling a calibration.
OK Cancels a calibration process and clears the measurement data of
standard.
:SENS{1-16}:CORR:COLL:CLE
Cancel Returns to the softkey display screen one level higher.
Return Returns to the softkey display screen one level higher.
3-Port TRL Cal
*1
Displays softkeys for executing 3-port TRL calibrations.
Select Ports
*2
Displays softkeys for selecting test ports.
1-2-3 Selects test ports 1, 2, and 3.
:SENS{1-16}:CORR:COLL:METH:TRL3 1,2,3
1-2-4 Selects test ports 1, 2, and 4.
:SENS{1-16}:CORR:COLL:METH:TRL3 1,2,4
1-3-4 Selects test ports 1, 3, and 4.
:SENS{1-16}:CORR:COLL:METH:TRL3 1,3,4
2-3-4 Selects test ports 2, 3, and 4.
:SENS{1-16}:CORR:COLL:METH:TRL3 2,3,4
Cancel Returns to the softkey display screen one level higher.
Thru/Line Displays softkeys for executing THRU/LINE calibrations. Symbols x, y and z refer to the three test ports selected
in the
Select Ports menu (x, y, and z are always 1, 2, and 3, respectively, for models with Option 313 or 314).
x-y Thru/Line Executes a THRU/LINE calibration on test ports x and y.
:SENS{1-16}:CORR:COLL:TRLT x,y
:SENS{1-16}:CORR:COLL:TRLT y,x
x-z Thru/Line Executes a THRU/LINE calibration on test ports x and z.
:SENS{1-16}:CORR:COLL:TRLT x,z
:SENS{1-16}:CORR:COLL:TRLT z,x
y-z Thru/Line Executes a THRU/LINE calibration on test ports y and z.
:SENS{1-16}:CORR:COLL:TRLT y,z
:SENS{1-16}:CORR:COLL:TRLT z,y
Return Returns to the softkey display screen one level higher
Key Operation Function SCPI Command
