Appendix D 673
Softkey Functions
Calibration Menu
D. Softkey Functions
(Continued)
Calibrate
Adapter Removal
Displays softkeys for executing adapter removal/insertion.
Select Port Displays softkeys for selecting a test port.
1 Selects test port 1.
:SENS{1-16}:CORR:COLL:METH:ADAP:REM
1
2 Selects test port 2.
:SENS{1-16}:CORR:COLL:METH:ADAP:REM
2
3
*1
Selects test port 3.
:SENS{1-16}:CORR:COLL:METH:ADAP:REM
3
4
*2
Selects test port 4.
:SENS{1-16}:CORR:COLL:METH:ADAP:REM
4
Cancel Returns to the softkey display screen one level higher.
Cal Kit Displays softkeys for selecting calibration kits.
:SENS{1-16}:CORR:COLL:CKIT
Open Executes an OPEN calibration on the test port selected in the Select
Port
menu.
:SENS{1-16}:CORR:COLL:OPEN
Short Executes a SHORT calibration on the test port selected in the Select
Port
menu.
:SENS{1-16}:CORR:COLL:SHOR
Load Executes a LOAD calibration on the test port selected in the Select
Port
menu.
:SENS{1-16}:CORR:COLL:LOAD
Adapter Length Sets the adapter length on the test port selected in the Select Port
menu.
:SENS{1-16}:CORR:COLL:ADAP{1-4}:LENG
Done Terminates a calibration process and calculates the calibration
coefficients.
:SENS{1-16}:CORR:COLL:SAVE
Cancel Displays softkeys for canceling a calibration.
OK Cancels a calibration process and clears the measurement data of
standard.
:SENS{1-16}:CORR:COLL:CLE
Cancel Returns to the softkey display screen one level higher.
Return Returns to the softkey display screen one level higher.
Key Operation Function SCPI Command
