Softkey Functions
Calibration Menu
(Continued)
ECal Displays softkeys for executing ECal (Electronic Calibrations).
:CALC{1-16}:SEL:FORM GDEL
1-Port ECal Displays softkeys for executing 1-port ECal
Port 1 Executes a 1-port ECal on test port 1.
:SENS{1-16}:CORR:COLL:ECAL:SOLT1 1
Port 2 Executes a 1-port ECal on test port 2.
:SENS{1-16}:CORR:COLL:ECAL:SOLT1 2
Port 3
*1
Executes a 1-port ECal on test port 3.
:SENS{1-16}:CORR:COLL:ECAL:SOLT1 3
Port 4
*2
Executes a 1-port ECal on test port 4.
:SENS{1-16}:CORR:COLL:ECAL:SOLT1 4
Return Returns to the softkey display screen one level higher.
2-Port ECal Options 213 and 214: Execute a 2-port ECal.
Options 313, 314, 413, and 414: Display softkeys for executing a 2-port ECal.
Port 1-2
*1
Executes a 2-port ECal on test ports 1 and 2.
:SENS{1-16}:CORR:COLL:ECAL:SOLT2 1,2
Port 1-3
*1
Executes a 2-port ECal on test ports 1 and 3.
:SENS{1-16}:CORR:COLL:ECAL:SOLT2 1,3
Port 1-4
*2
Executes a 2-port ECal on test ports 1 and 4.
:SENS{1-16}:CORR:COLL:ECAL:SOLT2 1,4
Port 2-3
*1
Executes a 2-port ECal on test ports 2 and 3.
:SENS{1-16}:CORR:COLL:ECAL:SOLT2 2,3
Port 2-4
*2
Executes a 2-port ECal on test ports 2 and 4.
:SENS{1-16}:CORR:COLL:ECAL:SOLT2 2,4
Port 3-4
*2
Executes a 2-port ECal on test ports 3 and 4.
:SENS{1-16}:CORR:COLL:ECAL:SOLT2 3,4
Return
*1
Returns to the softkey display screen one level higher.
3-Port ECal Options 313 and 314: Execute a 3-port ECal.
Options 413 and 414: Display softkeys for executing a 3-port ECal.
Port 1-2-3
*2
Executes a 3-port ECal on test ports 1, 2, and 3.
:SENS{1-16}:CORR:COLL:ECAL:SOLT3 1,2,3
Port 1-2-4
*2
Executes a 3-port ECal on test ports 1, 2, and 4.
:SENS{1-16}:CORR:COLL:ECAL:SOLT3 1,2,4
Port 1-3-4
*2
Executes a 3-port ECal on test ports 1, 3, and 4.
:SENS{1-16}:CORR:COLL:ECAL:SOLT3 1,3,4
Port 2-3-4
*2
Executes a 3-port ECal on test ports 2, 3, and 4.
:SENS{1-16}:CORR:COLL:ECAL:SOLT3 2,3,4
Return
*2
Returns to the softkey display screen one level higher.
4-Port ECal
*2
Executes a 4-port ECal.
:SENS{1-16}:CORR:COLL:ECAL:SOLT4
1,2,3,4
Thru ECal Displays softkeys for executing a THRU ECal.
2-1 (S21) Executes a THRU ECal for test port 1→2.
:SENS{1-16}:CORR:COLL:ECAL:THRU 2,1
3-1 (S31)
*1
Executes a THRU ECal for test port 1→3.
:SENS{1-16}:CORR:COLL:ECAL:THRU 3,1
4-1 (S41)
*2
Executes a THRU ECal for test port 1→4.
:SENS{1-16}:CORR:COLL:ECAL:THRU 4,1
1-2 (S12) Executes a THRU ECal for test port 2→1.
:SENS{1-16}:CORR:COLL:ECAL:THRU 1,2
3-2 (S32)
*1
Executes a THRU ECal for test port 2→3.
:SENS{1-16}:CORR:COLL:ECAL:THRU 3,2
4-2 (S42)
*2
Executes a THRU ECal for test port 2→4.
:SENS{1-16}:CORR:COLL:ECAL:THRU 4,2
1-3 (S13)
*1
Executes a THRU ECal for test port 3→1.
:SENS{1-16}:CORR:COLL:ECAL:THRU 1,3
2-3 (S23)
*1
Executes a THRU ECal for test port 3→2.
:SENS{1-16}:CORR:COLL:ECAL:THRU 2,3
4-3 (S43)
*2
Executes a THRU ECal for test port 3→4.
:SENS{1-16}:CORR:COLL:ECAL:THRU 4,3
1-4 (S14)
*2
Executes a THRU ECal for test port 4→1.
:SENS{1-16}:CORR:COLL:ECAL:THRU 1,4
2-4 (S24)
*2
Executes a THRU ECal for test port 4→2.
:SENS{1-16}:CORR:COLL:ECAL:THRU 2,4
3-4 (S34)
*2
Executes a THRU ECal for test port 4→3.
:SENS{1-16}:CORR:COLL:ECAL:THRU 3,4
Return Returns to the softkey display screen one level higher.
Key Operation Function SCPI Command
