682 Appendix D
Softkey Functions
Calibration Menu
(Continued)
Port Extensions
Auto Port
Extension
Adjust Mismatch Enables/disables the function to use the DC loss value for the
calculation.
:SENS{1-16}:CORR:EXT:AUTO:DCOF
Include Enables/disables the loss value calculation.
:SENS{1-16}:CORR:EXT:AUTO:LOSS
Return Returns to the softkey display screen one level higher.
Extensions Enables or disables the port extension function.
:SENS{1-16}:CORR:EXT
Extension Port 1 Sets the value for test port 1 extension (sec.).
:SENS{1-16}:CORR:EXT:PORT 1
Extension Port 2 Sets the value for test port 2 extension (sec.).
:SENS{1-16}:CORR:EXT:PORT 2
Extension Port 3
*1
Sets the value for test port 3 extension (sec.).
:SENS{1-16}:CORR:EXT:PORT 3
Extension Port 4
*2
Sets the value for test port 4 extension (sec.).
:SENS{1-16}:CORR:EXT:PORT 4
Loss Sets the loss value.
Select Ports Display the softkey to select the test port.
Port 1 Select test port 1. None
Port 2 Select test port 2. None
Port 3 Select test port 3. None
Port 4 Select test port 4. None
Return Returns to the softkey display screen one level higher.
Loss1 Toggles on/off loss 1 on the selected port.
:SENS{1-16}:CORR:EXT:PORT{1-4}:INCL1
Loss1 Sets the loss value of loss 1 on the selected port.
:SENS{1-16}:CORR:EXT:PORT{1-4}:LOSS1
Freq1 Sets the frequency of loss 1 on the selected port.
:SENS{1-16}:CORR:EXT:PORT{1-4}:FREQ1
Loss2 Toggles on/off the loss 2 on the selected port.
:SENS{1-16}:CORR:EXT:PORT{1-4}:INCL2
Loss2 Sets the loss value of the loss 2 on the selected port.
:SENS{1-16}:CORR:EXT:PORT{1-4}:LOSS2
Freq2 Sets the frequency of the loss 2 on the selected port.
:SENS{1-16}:CORR:EXT:PORT{1-4}:FREQ2
Loss at DC Sets the DC loss value.
:SENS{1-16}:CORR:EXT:PORT{1-4}:LDC
Return Returns to the softkey display screen one level higher.
Return Returns to the softkey display screen one level higher.
Velocity Factor Sets the velocity factor.
:SENS{1-16}:CORR:RVEL:COAX
Set Z0 Sets the system characteristic impedance value.
:SENS:CORR:IMP
Key Operation Function SCPI Command
